PolyFlex®Heavy

PolyFlex® contains a unique organic compound which is added to the Polyurethane and attracts air borne moisture to create a continuous circuit that removes static build up as product moves through the duct. PolyFlex does not lose its antistatic properties as it wears and the helix does not require grounding.

Heavy weight and flexible polyurethane ducting


Technical Data

Further diameters avaliable upon request. Technical data are based on +20°C

Product Code
(dia)
Wire Thickness
(mm)
Weight
(kg/m)
Bend Radius
(mm)
Max Pressure (bar)
Max Vacuum (bar)
POLYFLEXHVY032
1.0/1.5
0.250
45
2.10
0.50
POLYFLEXHVY040
1.5/1.9
0.350
60
2.00
0.45
POLYFLEXHVY052
1.5/1.9
0.440
75
1.80
0.40
POLYFLEXHVY063
1.5/1.9
0.525
90
1.60
0.35
POLYFLEXHVY076
1.5/1.9
0.612
105
1.50
0.35
POLYFLEXHVY082
1.5/1.9
0.670
120
1.20
0.30
POLYFLEXHVY102
1.8/2.2
1.020
150
1.00
0.30
POLYFLEXHVY115
1.8/2.2
1.150
180
0.08
0.25
POLYFLEXHVY120
1.8/2.2
1.220
180
0.80
0.25
POLYFLEXHVY127
1.8/2.2
1.280
185
0.75
0.25
POLYFLEXHVY140
1.8/2.2
1.400
210
0.60
0.20
POLYFLEXHVY152
1.8/2.2
1.460
225
0.50
0.20
POLYFLEXHVY160
1.8/2.2
1.550
235
0.50
0.20
POLYFLEXHVY180
1.8/2.2
1.697
260
0.45
0.15
POLYFLEXHVY203
1.8/2.2
1.940
300
0.35
0.12
POLYFLEXHVY229
1.8/2.2
2.550
338
0.30
0.11
POLYFLEXHVY254
3.0/3.5
3.150
375
0.25
0.10
POLYFLEXHVY275
3.0/3.5
3.465
413
0.23
0.10
POLYFLEXHVY305
3.0/3.5
3.780
450
0.20
0.09
POLYFLEXHVY356
3.0/3.5
4.410
525
0.15
0.09
POLYFLEXHVY406
3.0/3.5
5.050
600
0.10
0.08
POLYFLEXHVY450
3.0/3.5
6.710
675
0.08
0.06
POLYFLEXHVY457
3.0/3.5
6.710
675
0.08
0.06

Material
Polyester-polyurethane

Wall Thickness
25mm - 39mm = 0.8mm
40mm - 99mm = 1.0mm
100mm - 139mm = 1.15mm
140mm - 210mm = 1.2mm
215mm - 500mm = 1.4mm

Colour
Clear

Single Length
10m rolls / can cut length to order

Temperature Resistance
- 40°C up to + 100°C

Superior Technology
PolyFlex Heavy contains a unique organic compound which is added to the Polyurethane and attracts air borne moisture to create a continuous circuit that removes static build up as product moves through the duct. PolyFlex Heavy does not lose its antistatic properties as it wears and the helix does not require grounding.

Applications
Suction of abrasive materials and transport of granules

Properties

  1. Antistatic @ < 108 ohms
  2. Solid construction
  3. Good oil resistance
  4. Excellent abrasion resistance smooth bore
